DNE Cobot Welding Cart

The DNE Cobot Welding Cart utilizes an ABB collaborative robot (Cobot) which is an industrial robot arm designed for operator safety, ease of use and programmability. The Cobot design and operating speeds allow for use in areas with minimal safety guarding which would be prohibitive to more conventional industrial robots.

The operator can load and unload from a single station that is shared with the robot envelope. This allows the worker the ability to address high-mix, low-volume operating scenarios in a small footprint.

Product Overview PDF

Compact and Efficient Design

The cart features a fully integrated setup, combining the robot, controller, and welder into a single, mobile unit, ensuring a streamlined operation within a small footprint.

User-Friendly Interface

The MWES Easy-Arc software offers an intuitive user experience, making it simple to teach the robot new tasks and manage production efficiently.

Advanced Safety and Precision

Equipped with the ABB GoFa CRB 15000 Cobot, the cart delivers top-tier safety and precision with superior power and force-limiting capabilities, allowing for high-speed operation with minimal safety guarding.

About the DNE Cobot Welding Cart

Automated Welding Cart

Powder-coated steel frame

Integrated spool holder

Swing arm for pendant

Integrated robot, controller and welder within the cart

Integrated Siegmund Modular TableTop

Casters w/ wheel locks for easy movement

Expandable controller for additional options and accessories

Single 480v 3-phase power drop required

1-year warranty included

ABB GoFa CRB 15000 Cobot

Superior power and force limiting performance through integrated torque sensors

Safe robot design - rounded geometry, no pinch/trap points

Safety certified Category 3, PL d

TCP speed of up to 2.2m/s- GoFa is faster than other cobots in its class

950mm reach - 12% longer than comparable 5kg cobots

1000mm x 1400mm Workspace (3.2' x 4.6')

Bluco modular solutions allow you to fixture with the repeatable precision the robot requires +/-0.005 inch repeatable accuracy achievable when modular solutions are combined with robotic welding systems

MWES Easy-Arc Software

This software provides an intuitive user interface to teach the robot new parts and run production
